NOTE: Our complete catalog is not available for direct online purchase, refer to the Status Column for purchasing options. Items that do not have an Add to Cart button must be purchased from an Authorized Distributor.

Model	Cat. #	Description	List Price	Quantity/Status
C.A 6116N	2138.06	Multi-Function Installation Model C.A 6116N NIST Calibration ($160.00 each)	$2,940.00	Consult Factory for Availability

Model	C.A 6116N
Cat. #	2138.06
Description	Multi-Function Installation Model C.A 6116N
List Price	$2,940.00
Consult Factory for Availability

Model CA 6116N- Cat. #2138.06: Includes carrying bag, US power cord and charger, Li-lon battery pack, USB A/B cable, set of (3) 3-prong color-coded safety voltage leads (red, blue, green), set of (3) color-coded test probes (red, blue, green), set of (3) alligator clips (red/blue/green), set of (2) color-coded safety leads (red/black) 4mm straight plug, 3-prong US measurement cord, remote test probe, wrist strap, hands-free strap, multi-lingual safety cared, and a USB drive with DataView® software and a user manual.

Model CA 6116N Kit- Cat. #2138.10: Includes carrying bag, AC Current Probe Model C177A, US power cord and charger, Li-lon battery pack, USB A/B cable, set of (3) 3-prong color-coded safety voltage leads (red, blue, green), set of (3) color-coded test probes (red, blue, green), set of (3) alligator clips (red/blue/green), set of (2) color-coded safety leads (red/black) 4mm straight plug, 3-prong US measurement cord, remote test probe, wrist strap, hands-free strap, multi-lingual safety cared, and a USB drive with DataView® software and a user manual.

CONTINUITY / RESISTANCE
I Rated • Range • Resolution	I > 200 mA • 39.99 Ω • 0.01Ω ± (1.5 % of R + 2 cts) 12 mA • (39.99 and 399.9) Ω • (0.01 and 0.1) Ω •± (1.5 % of R + 5 cts) with beep
Range • Resolution • Accuracy	4 kΩ • 1 Ω • ±(1.5 % of R + 5 cts) (40 to 400) kΩ • (10 - 100) Ω • ±(1.5 % of R + 2 cts)
INSULATION
Rated Voltage	U test: (50, 100, 250, 500, and 1000) VDC
Range • Resolution • Accuracy	0.01 MΩ to 2 GΩ • 0 kΩ to 1 MΩ • ± (5 % of R + 3 cts)
Short Circuit Current	≤ 3 mA
3P GROUND
Range • Resolution • Accuracy	(0.50 to 40) Ω • 0.01 Ω • ± (2 % of R + 10 cts) (40 Ω to 15 kΩ) • (0.1 to 1) Ω • ± (2 % of R + 2 cts ) (15 to 40) kΩ • 10 Ω • ± (10 % of R + 2 cts )
Others	Measurement of resistance of auxiliary stakes RH & RS (up to 40 kΩ)
Ufk	Complies with SEV 3569
1P SELECTIVE GROUND
Range Resolution Accuracy	(0.20 to 39.99) Ω (40 to 399.9) Ω (0.01 – 0.1) Ω ± (10 % of R + 10 cts) (ISel via clamp)
LOOP IMPEDANCE (Zs (L-PE0 AND Zi (L-N OR L-L) – 1P LIVE GROUND
Live Ground Installation Voltage Frequecy	(90 to 500) V (15.8 to 17.5) Hz (45 to 65) Hz
High-current mode with TRIP Zs (L- PE) & Zi (L- N or L - L) Range • Resolution • Accuracy	Max. test current: 7.5 A (0.100 to 0.5) Ω • 0.001 Ω • ± (10 % of R + 20 cts) (0.5 to 3.999) Ω • 0.001 Ω • ± (5 % of R + 20 cts) (3.999 to 39.99) Ω • 0.01 Ω • ±(5 % of R + 2 cts) (39.99 to 399.99) Ω • 0.1 Ω • ± (5 % of R + 2 cts)
NO TRIP mode (Zs (L – PE) Only) Range • Resolution • Accuracy	Test current (6, 9,and 12) mA (as required) (0.20 to 0.99) Ω • 0.01 Ω • ± (15 % of R + 10 cts) (1.00 to 1.99) Ω • 0.01 Ω • ± (15 % of R + 3 cts) (2.00 to 39.99) Ω • 0.01 Ω • ± (10 % of R + 3 cts) (40.00 to 399.9) Ω • 0.1Ω • ± (5 % of R + 2 cts) (400 to 3999) Ω • 1 Ω • ± (5 % of R + 2c ts)
Calculation of IK short circuit current (PFC (Zs), I Sc PSCC (Zi)	Fault current and short-circuit current: (0.1 to 20) kA
Others	Measurement of the resistive and inductive components of Zs and Zi impedances
AC and type RCDs
Installation Voltage Frequency	(90 to 500 ) V (15.8 to 17.5) Hz and (45 to 65) Hz
IΔn	10/30/100/500/650/1000 (90 to 280) V or variable ramp and pulse test
N-Trip Test	At ½ IΔn – Duration 1000 ms or 2000 ms
Ramp Mode	0.2 to 0.5 x IΔn(Uf) / 0.3 x IΔn to 1.06 IΔn increments of 3.3% x IΔn
Trip test: R: Range / Resolution / Accuracy	0.2 to 0.5 x IΔn(Uf) / 0.5 x IΔn / 2 x IΔn(selective) / 5 x IΔn Pulse: 0 to 500ms/0.1 and 1ms / 2ms, Ramp mode: 0 to 200ms / 0.1ms / 2 ms
OTHER MEASUREMENTS
Current by Current Probe C177A	5.0 mA t0 199.9 A
Current by Current Probe MN77	(1 mA*) 5.0 mA to 19.99 A
Voltage	0 to 550 VAC/DC / DC and (158 to 500) Hz
Frequency	(10 to 500) Hz
Phase Rotation	(20 to 500) VAC
Active Power	(0 to 110) kW single phase – (0 to 330) kW three-phase Simultaneous display of voltage and current waveforms
Harmonics	Voltage and Current up to 50th order THD-F / THD-R
GENERAL SPECIFICATIONS
Display	Large 5.7 inch backlit graphic color LCD 320 x 240 pixels
Storage/Communication	USB for data transfer to DataView^® software (included)
Power Supply	Rechargeable Lithium-Ion 10.8 V, 5.8 A • h
Battery Life	Up to 30 hours
Protection	IP 53 / IK04
Dimensions Weight	(11 x 7.48 x 5.04) in (280 x 190 x 128) mm 4.85 lbs (2.2 kg)
EMC	IEC61326-1
Electrical Safety	IEC61010-1 – 600 V CAT III 300 V CAT IV – IEC 61557

User Manuals

Model 6116/6117

Battery Pack Replacement for PowerPad® IV 8345, Oscilloscope Models OX 9000 Series, and Multi-Function Installation Tester Models CA 6116N & CA6117

Battery Recharge Time / Rechargeable NiMH Notice

Quick Start Guides

Model 6116/6117

Brochures

Multi-function Installation Tester Brochure

AEMC^® Instruments Product Line Brochure

Comparison Charts

ICT Comparison Chart

Software

DataView^® Software

Videos

Battery Pack (Cat. #2960.47) Replacement Procedure (PowerPad ^® IV 8345, OX 9000 Series, Installation Testers CA 6116N & CA 6117

Understanding Insulation Resistance Testing

What's New in DataView 3.50

Cat. #	Description	List Price	Quantity/Status
2135.35	Ground Resistance Test Kit for 3-Point Testing - 150ft Test Kit for 3-Point Testing, Kit (Carrying Bag, [2] 150 ft Color-coded Leads on Spools (Red/Blue), [1] 30 ft Lead (Green), [2] 5 ft Color-coded Leads (Red/Blue), [2] 14.5" T-shaped Auxiliary Ground Electrodes, [1] Set of 5, Spaded Lugs and [1] 100 ft AEMC® Tape Measure)	$595.00
2135.36	Ground Resistance Test Kit for 4-Point Testing - 300ft Test Kit for 4-Point Testing, Kit (Carrying Bag, [2] 300 ft Color-coded Leads on Spools (Red/Blue), [2] 100 ft Color-coded Leads (hand tied-Green/Black), [2] 5 ft Color-coded Leads (Red/Blue), [4] 14.5" T-shaped Auxiliary Ground Electrodes, [1] Set of 5, Spaded Lugs and [1] 100 ft AEMC® Tape Measure)	$760.00
2138.54	Continuity Probe for use with Megohmmeters and Installation Testers	$125.00
2155.75	Megohmmeter Test Probe (600V CAT IV) for Models 6522-6536, 6116N & 6117	$265.00
2960.47	Battery – Replacement 5.8AH 61.9Wh Li-ion Battery Pack for Models C.A6116N, C.A6117, OX9104-OX9304, & 8345 Instruction Sheet	$374.00	Consult Factory for Availability
2140.52	Cat.# 2140.52 is DISCONTINUED. Click on replacement items: Cat #5100.00: Clip - Safety Alligator - Red (1000V CAT IV, 15A, UL V2). DISCONTINUED	$0.00	Discontinued
2140.53	Cat.# 2140.53 DISCONTINUED Click on replacement items: Cat #5000.99: Clip - Safety Alligator - Black (1000V CAT IV, 15A, UL V2)).;	$0.00	Discontinued
2140.69	Cat.# 2140.69 is DISCONTINUED. Click on replacement item: Cat #5100.06: Clip – safety alligator – green (1000V CAT IV, 15A, UL)	$0.00	Discontinued
2140.70	Cat.# 2140.70 is DISCONTINUED. Click on replacement items: Cat #5100.00: Clip – safety alligator – red (1000V CAT IV, 15A, UL V2) Cat #5100.04: Clip – safety alligator – blue (1000V CAT IV, 15A, UL V2) Cat #5100.06: Clip – safety alligator – green (1000V CAT IV, 15A, UL)	$0.00
2140.71	Probe - Set of 3, Color-coded test probes (red, blue & green) for use w/C.A 6116	$0.00	Discontinued

Model
Cat. #	2135.35
Description	Ground Resistance Test Kit for 3-Point Testing - 150ft Test Kit for 3-Point Testing, Kit (Carrying Bag, [2] 150 ft Color-coded Leads on Spools (Red/Blue), [1] 30 ft Lead (Green), [2] 5 ft Color-coded Leads (Red/Blue), [2] 14.5" T-shaped Auxiliary Ground Electrodes, [1] Set of 5, Spaded Lugs and [1] 100 ft AEMC® Tape Measure)
List Price	$595.00

Model
Cat. #	2135.36
Description	Ground Resistance Test Kit for 4-Point Testing - 300ft Test Kit for 4-Point Testing, Kit (Carrying Bag, [2] 300 ft Color-coded Leads on Spools (Red/Blue), [2] 100 ft Color-coded Leads (hand tied-Green/Black), [2] 5 ft Color-coded Leads (Red/Blue), [4] 14.5" T-shaped Auxiliary Ground Electrodes, [1] Set of 5, Spaded Lugs and [1] 100 ft AEMC® Tape Measure)
List Price	$760.00

Model
Cat. #	2138.54
Description	Continuity Probe for use with Megohmmeters and Installation Testers
List Price	$125.00

Model
Cat. #	2155.75
Description	Megohmmeter Test Probe (600V CAT IV) for Models 6522-6536, 6116N & 6117
List Price	$265.00

Model
Cat. #	2960.47
Description	Battery – Replacement 5.8AH 61.9Wh Li-ion Battery Pack for Models C.A6116N, C.A6117, OX9104-OX9304, & 8345 Instruction Sheet
List Price	$374.00
Consult Factory for Availability

Model
Cat. #	2140.52
Description	Cat.# 2140.52 is DISCONTINUED. Click on replacement items: Cat #5100.00: Clip - Safety Alligator - Red (1000V CAT IV, 15A, UL V2). DISCONTINUED
List Price	$0.00
Discontinued

Model
Cat. #	2140.53
Description	Cat.# 2140.53 DISCONTINUED Click on replacement items: Cat #5000.99: Clip - Safety Alligator - Black (1000V CAT IV, 15A, UL V2)).;
List Price	$0.00
Discontinued

Model
Cat. #	2140.69
Description	Cat.# 2140.69 is DISCONTINUED. Click on replacement item: Cat #5100.06: Clip – safety alligator – green (1000V CAT IV, 15A, UL)
List Price	$0.00
Discontinued

Model
Cat. #	2140.70
Description	Cat.# 2140.70 is DISCONTINUED. Click on replacement items: Cat #5100.00: Clip – safety alligator – red (1000V CAT IV, 15A, UL V2) Cat #5100.04: Clip – safety alligator – blue (1000V CAT IV, 15A, UL V2) Cat #5100.06: Clip – safety alligator – green (1000V CAT IV, 15A, UL)
List Price	$0.00

Model
Cat. #	2140.71
Description	Probe - Set of 3, Color-coded test probes (red, blue & green) for use w/C.A 6116
List Price	$0.00
Discontinued
