| Model | Cat. # | Description | List Price | Quantity/Status | Distributor Stock Check |
|---|---|---|---|---|---|
| MA194-24-BK | 2140.80 | MiniFlex® Sensor Model MA194-24-BK (Replaces Cat. #2140.78) for Models 3945/3945-B, 8220, 8230, 8333, 8335, 8336, 8345, 8435, 8436 & PEL Series | $335.00 |
|
|
|
||||||||||
| Clamping Diameter | 24 in (609 mm) |
| Current Range | 3000 AAC |
| Measurement Range | 0.1 to 3000 AAC (10,000 A peak) |
| Lead Length | 10 ft (3 m) |
| Output Termination | Proprietary connector |
| Accuracy (Typical) | 1% |
| Power Source | N/A |
| Compatibility | AEMC PowerPads and PELs (limited range with models 8220, 8230, 8435) |
| Operating Temperature | (14 to +131) °F (-10 to +55) °C; (10 to 85) % RH |
| Storage Temperature | (-40 to +158) °F (-40 to +70 ) °C; (10 to 90) % RH |
| Dimensions | (4 x 2.5 x 1.1) in (103 x 63 x 28) mm |
| Weight | 1.94 oz (55 g) |
| Pollution Degree | 2 |
| Protection | IK 04, IP 40 |
| Safety Compliance | IEC 61010-1, EN/IEC 61010-2-032, 1000 V CAT III, 600 V CAT IV |
